EasyFit Heavy Duty British Douglas Fir Softwood Diamante Pergola Kit | Buy Online from the specialists at UK Timber Limited

EasyFit Heavy Duty British Douglas Fir Softwood Diamante Pergola Kit - FREE DELIVERY

MODEL EFDMHD-DF

CONDITION NEW

£989.99
From £742.49 + VAT Save 25%
Tax excluded

EasyFit Heavy Duty British Douglas Fir Softwood Diamante Pergola Kits, a striking five-post corner design, easy to assemble and comprising high-quality components.

  • Larger dimension material to provide solidity and support.
  • Diamond (Diamante) footprint with five posts: a feature pergola for the corner of a garden, patio or deck.
  • Sawn and machined on-site right here in the Midlands.
  • The most durable of domestic softwoods, beauty as standard and requires no treatment.
  • Planed all round to a smooth, visually appealing finish.
  • Shipped with pre-cut notches and all required fixings.
  • Select post length (2400 or 3000) and rafter end profile in the dropdowns.
  • Choose from 3 rafter end designs: Chamfered, Square Edged and Sleek.
  • Stock sizes 2400, 3000 and 3600 mm.
  • FREE DELIVERY TO MAINLAND UK*

*except the Scottish Highlands (including IV and KW postcodes) and British Isles where additional charges may apply.

Size (mm): 2400 x 2400
Rafter Profile: Square Edged
Post Size (mm): 2400 x 150 x 150
Quantity

TOTAL PRICE FOR THIS ITEM £742.49 +VAT

In Stock

100% Secure Payments

These Diamante kits are a must-have purchase should you want a show-piece for outdoor entertaining, or a support for the growth of climbing plants.

The components of your kit are made from untreated British Douglas Fir (150 x 50 mm rails) that has been pre-cut and machined, eliminating the need for annual retreatment and meaning that you will only require basic tools to assemble using the supplied instructions.

These purposely designed, simple to fit, slot together pergolas really are a dream to construct. Just slot them together in their pre-cut slots, then for additional strength pop a screw (supplied) at each joint.

Instructions
Assembly drawings for every size and end profile can be downloaded from the Attachments tab.

Our Heavy Duty Diamante Pergola Kits are available in three stock sizes and contain the following depending on the size required:

2400mm Diamante

  • 5 x Douglas Fir Softwood Notched Posts 150mm x 150mm - (Selected Length from Dropdown)
  • 2 x Douglas Fir Softwood rail 3000mm x 150 x 50mm (cut to the Diamante cutting list)
  • 4 x Douglas Fir Softwood rail 2400mm x 150 x 50mm (cut to the Diamante cutting list)
  • 5 x Douglas Fir Softwood rail 1800mm x 150 x 50mm (cut to the Diamante cutting list)
  • 22 x Timber Titan landscaping screws 100mm (2 per rafter and 2 per bearer), plus 2 per post seat

3000mm Diamante

  • 5 x Douglas Fir Softwood Notched Posts 150mm x 150mm - (Selected Length from Dropdown)
  • 2 x Douglas Fir Softwood rail 3600mm x 150 x 50mm (cut to the Diamante cutting list)
  • 4 x Douglas Fir Softwood rail 3000mm x 150 x 50mm (cut to the Diamante cutting list)
  • 1 x Douglas Fir Softwood rail 2400mm x 150 x 50mm (cut to the Diamante cutting list)
  • 4 x Douglas Fir Softwood rail 1800mm x 150 x 50mm (cut to the Diamante cutting list)
  • 22 x Timber Titan landscaping screws 100mm (2 per rafter and 2 per bearer), plus 2 per post seat

3600mm Diamante

  • 5 x Douglas Fir Softwood Notched Posts 150mm x 150mm - (Selected Length from Dropdown)
  • 2 x Douglas Fir Softwood rail 4200mm x 150 x 50mm (cut to the Diamante cutting list)
  • 4 x Douglas Fir Softwood rail 3600mm x 150 x 50mm (cut to the Diamante cutting list)
  • 3 x Douglas Fir Softwood rail 3000mm x 150 x 50mm (cut to the Diamante cutting list)
  • 4 x Douglas Fir Softwood rail 1800mm x 150 x 50mm (cut to the Diamante cutting list)
  • 26 x Timber Titan landscaping screws 100mm (2 per rafter and 2 per bearer), plus 2 per post seat

Optional wind braces and post supports are available as add-ons in the Pergola Configurator.

Wind braces are offered on all our pergola kits: choose a straight wind brace or a curved wind brace.

EFDMHD-DF-2400-2400x150-SQ
5000 Items

Download

HD Diamante assembly drawings

Customer assembly drawings, all sizes and end profiles

Download (896.86KB)
